| 机型 (Model) | 单位 (Unit) | HM618 | HM618S | ||
|---|---|---|---|---|---|
| 工作台 (Workbench) | 工作台尺寸 (Workbench Size) | 毫米 (mm) | 150x450 | 150x450 | |
| 最大研磨长度（X轴） (Max Grinding Length (X-axis)) | 毫米 (mm) | 500 | 470 | ||
| 最大研磨宽度（Y轴） (Max Grinding Width (Y-axis)) | 毫米 (mm) | 175 | 160 | ||
| 主轴至工作台距离（Z轴） (Spindle to Workbench Distance (Z-axis)) | 毫米 (mm) | 360 | 400 | ||
| 磁盘尺寸 (Disk Size) | 毫米 (mm) | 150x400 | 150x400 | ||
| 进给 (Feed) | Y轴手轮每刻度进给 (Y-axis Handwheel Feed per Graduation) | 毫米 (mm) | 0.01 | 0.02 (0.001) | |
| Y轴手轮每转进给 (Y-axis Handwheel Feed per Revolution) | 毫米 (mm) | 2.5 | 5 (0.2) | ||
| Z轴手轮每刻度进给 (Z-axis Handwheel Feed per Graduation) | 毫米 (mm) | 0.01 | 0.005 (0.0002) | ||
| Z轴手轮每转进给 (Z-axis Handwheel Feed per Revolution) | 毫米 (mm) | 1.25 | 1 (0.05) | ||
| 磨头 (Grinding Head) | 砂轮尺寸 (Grinding Wheel Size) | 毫米 (mm) | 180x13x31.75 | 180x16x31.75 | |
| 主轴转速 (Spindle Speed) | 转/分钟 (rpm) | 2850 | 3600 | ||
| 精度 (Accuracy) | 工作台平行度 (Workbench Parallelism) | 毫米 (mm) | 0.005 | 0.002 | |
| 主轴跳动 (Spindle Jumping) | 毫米 (mm) | 0.005 | 0.002 | ||
| 表面粗糙度 (Surface Roughness) | 微米 (μm) | Ra0.32 | Ra0.25 | ||
| 功率 (Power) | 主轴电机功率 (Spindle Motor Power) | 千瓦 (kW) | 1.1 | 1.1 | |
| 机床总功率 (Total Power) | 千瓦 (kW) | 1.14 | 1.14 | ||
| 重量 (Weight) | 千克 (kg) | 800 | 850 | ||
| 外形尺寸 (Dimensions) | 毫米 (mm) | 1500x1120x1700 | 1400x1150x1980 | ||
Surface grinding machine(HM618)
Grinding Machine
Surface grinding machine(HM618)
- Precision Grinding: The Surface Grinding Machine (HM618) delivers precise and uniform surface finishes.
- Efficient Material Removal: Equipped with advanced grinding technology, it ensures efficient material removal for high-speed grinding operations.
- Durable Build: Constructed with robust materials, the HM618 guarantees durability and stability during grinding processes.
- Versatile Application: Suitable for a wide range of materials and components, offering versatility in grinding tasks.
