Taper Shank: Tolerance Grade AT3
Heat Treatment Hardness: HRC58±2
Product Material: 20CrMnTi
Main Body Accuracy: BT30/40 ≤ 0.003mm, BT50 ≤ 0.005mm
Product Advantages:
1. Modular design, tool head and tool holder connected via threaded connection.
2. Direct connection between tool holder and tool head eliminates the need for a collet chuck, reducing cumulative positioning errors from multiple setups.
3. Uniform cutting with the tool blade improves tool life, reducing surface vibrations caused by diameter deviation.
4. Replaceable tool heads ensure high repeatability in setup, suitable for both roughing and finishing operations.
5. Tool heads can accommodate various types of inserts, enabling versatile combinations with the tool holder. Even if part of the tool is damaged, immediate replacement is possible.
